Error code

Code

Interpretation

9

Crystal vibration anomaly

35

The gyroscope initialization is abnormal. Please check the main control panel.

25

Electronic control does not receive data from Bluetooth panel, check Bluetooth module and electronic connection.

26

Abnormal driving voltage, it is necessary to check whether the main board and battery voltage are normal.

36

The left motor Holzer sensor is abnormal. Please check the electrical wiring or replace the motor.

39

The right motor Holzer sensor is abnormal. Please check the electrical wiring or replace the motor.

11

The left motor current sensor is abnormal, so the main control board needs to be detected.

12

The left motor current sensor is abnormal, so the main control board needs to be detected.

13

The left motor current sensor is abnormal, so the main control board needs to be detected.

14

The right motor current sensor is abnormal, so the main control board needs to be detected.

15

The right motor current sensor is abnormal, so the main control board needs to be detected.

16

The right motor current sensor is abnormal, so the main control board needs to be detected.

2

The communication failed. Please check the Bluetooth module and the electronic control connection. Turn on and off 2 times continuously.

When these errors occur, the system enters the lock state and needs to be restarted.

46

The vehicle's left and right angles or inclination are too large to turn over.

42

Gyroscope data abnormity

44

Gyroscope data abnormity

43

Joystick error (driving process exception)

45

The motor speed is too large to exceed 12km.

48

Excessive rotation of vehicle

49

Calibration failure
